Muncy™ End Links
Muncy™ End Links are manufactured in the USA using a quality forging for a blend of strength and ductility, with a 5:1 Factor of Safety.
Muncy™ Quality USA Forgings
Everything produced by Muncy™ Industries is Made in USA. "USA" is Forged directly into our End Links, along with our name as the manufacturer, size, and heat number for traceability
Federal Specification
Muncy™ End Links are produced in accordance with the dimensional, performance, and testing requirements of RR-C-271F (Type XV) from sizes 5/8” through 7/8”. Parts are stocked painted Muncy Blue, and are available Hot Dip Galvanized upon request.
| Stock No. | Main Cable Diameter | Dimensions | WLL(lbs) | Weight lbs. Each | |||
|---|---|---|---|---|---|---|---|
| A | B | C | D | ||||
| EL-16 | 1/2 | 0.53 | 0.75 | 2.38 | 1.81 | 6,500 | 0.4 |
| EL-20 | 5/8 | 0.66 | 1.00 | 3.25 | 2.31 | 9,300 | 0.9 |
| EL-24 | 3/4 | 0.75 | 1.13 | 3.50 | 2.63 | 14,000 | 1.4 |
| EL-28 | 7/8 | 0.88 | 2.00 | 5.13 | 3.75 | 12,000 | 2.7 |
| EL-32 | 1 | 1.00 | 2.25 | 5.75 | 4.25 | 15,200 | 3.9 |
- Socketing Zinc
- Carbon Steel Open Swage Sockets
Other Materials Available
