Dillon GL Force Gauge


Model GL Force Gauge

Dillon GL Force Gauge
Part Number N kgf lbf
36321-0022 25 2.5 5.5
36321-0030 50 5 11
36321-0048 100 10 22
36321-0063 500 50 110
Accessories
52751-1885 Model CT manual tension = compression test stand


Specifications

  • Accuracy: +/- 0.4% of capacity
  • Tension/compression testing: Both
  • Overload protection: 120% minimum
  • Enclosure: Die cast metal
  • Power: Rechargeable battery or AC charger
  • Display type: 7 segment LCD, 4.5 digit with backlight
  • Data output: RS-232
  • Weight: 21 oz (610 g)
  • Operating temperature: 60o – 95oF (15o – 35oC)
  • Includes: Hook, plate, cone point, chisel, inverted chisel, extension rod, carry case, batteries, charger, user’s manual, calibration card
  • Battery charge: 10 hour operation from full charge
  • Accessories available: Universal test stand mounting plate, serial cable, quick couplers and adapters, test stands, popular grip assortment
  • Approvals: CE
  • Warranty: One year parts and labor
  • Shipping Weight: 1.5 kg (3.5 lb)
